GS 5390 RT

Opis stroja

Tehnička specifikacija / Technical specification

Težina / Weight (kg) 8357
Nosivost / Capacity (kg) 680
Radna visina / Working height (m) 18.2
Visina platforme / Platform height (m) 16.2
Visina sa spuštenom ogradom / Height stowed- rails lowered (m) 2.47
Najveća visina pri vožnji / Drive height maximum (m) 9.8
Dimenzije košare / Basket dimensions (cm) 183×657
Dimenzije košare bez proširenja / Basket dimensions without extensions (cm) 183×388
Maksimalni nagib pri vožnji / Gradeability – stowed (°) 50
Motor / Engine Diesel Deutz 56HP 42kW
Vuča / Traction 4×4
Kotači / Wheels (cm) 12-21.5
Vanjski krug okretanja platforme / Turning radius – outside (m) 5.33
Unutarnji krug okretanja platforme / Turning radius – inside (m) 2.16
Brzina vožnje uzbrdo / Drive speed uphill (km/h) 8
Brzina vožnje nizbrdo / Drive speed downhill (km/h) 1.1
Vrijeme podizanja / Lift time 55
Vrijeme spuštanja / Lower time 49
Transportna visina / Height – stowed (m) 2.15
Transportna dužina / Length – stowed (m) 4.88
Transportna širina / Width – stowed (m) 2.29
